Profile Extrusion: Elevating Façade with Civro’s Superior 6060 T6 Aluminium Profiles

Most aluminium doors and windows on the market use 6063 T5 aluminium profiles. As the value of architectural living spaces continues to rise, CIVRO has pioneered the use of higher-quality and higher-performance aluminium profiles to meet the increasingly demanding requirements for building façade solutions.


Since 2021, CIVRO has adopted the self-developed Euro-standard 6060 T6 aluminium profile, based on European standards. Compared to the 6063 T5 profile, CIVRO’s Euro-standard 6060 T6 offers significant advantages in various performance aspects, as illustrated in the chart below (showing key performance metrics).


Webster hardness

≥HW 10

≥HW 8

Tensile strength(Rm)

237N/m㎡

223N/m㎡

Proof strength, non-proportional extension(RP0.2)

212N/m㎡

189N/m㎡

Percentage elongation after fracture(A50mm)

11.5

10.5

Higher values indicate better performance

The Exceptional Performance Of Civro's Euro-Standard 6060 T6 Profiles Stems From:

Reliable Raw Materials

The use of A00 primary aluminium ingots with a purity level of ≥99.7% ensures the highest quality foundation for the profiles.

In-house Extrusion Facility

All CIVRO profiles are produced in-house at our own extrusion plant, which not only boosts production efficiency but, more importantly, allows complete control over quality, ensuring the delivery of products that meet the highest quality standards.

High Precision Fabrication

CIVRO profiles are precision-extruded and processed in our own extrusion factory, with exceptional performance across key metrics:

Tensile strength: 222MPa, offering outstanding structural strength and safety, ensuring the durability, stability, and reliability of the profiles

Yield strength: 200MPa, providing excellent structural strength and safety, guaranteeing the durability, stability, and reliability of the profiles

Webster hardness: HW 14 (actual test data), demonstrating superior impact resistance

Elongation at break: 11.5%, indicating excellent deformation resistance

Twist deviation: 0.09mm, tested on profiles with W*L=150mm*5000mm, showcasing excellent flatness and machining precision
