PW80IN Window | |
Design | |
Opening | Inwards opening |
Opening type | Side-hung, turn/tilt, tilt before turn |
Basic depth(mm) | 80 |
Vent frame depth(mm) | 70 |
Total face width of vent&frame(mm) | 67(Slender frame) |
76.5(Regular frame) | |
Face width of vent frame(mm) | 54 |
Total face width of vent, frame&mullion(mm) | 84 |
Face width of reinforcement mullion(mm) | 95 |
Concealed hinge | Yes |
Reinforcement mullion | Yes |
Surface finish | MED, powder coating |
Pluggable inwards opening flyscreen sash | Yes |
Fixed lights | Yes |
Vent data | |
Min.-max. vent height(mm),depending on window type | 600-2600 |
Min.-max. vent width(mm),depending on window type | 450-1200 |
Max. vent weight(Kg) | 130 |
Min.-max. glass thickness(mm) | Vent: 16-43 |
Frame: 16-53 | |
Implement scenario | |
Façade insert unit | Yes |
Conservatory insert unit | Yes |
Parameter | |
U values in W/(㎡·K) | 1.7 |
Sound reduction(dB), depending on glazing type | 35 |
Air permeability(m3/(m.h)) | 0.21 |
Water tightness(Pa) | 500 |
Wind load resistance(KPa) | ≤5 |
